DX-IC8

DX-IC8

In-Ceiling Speaker

In-Ceiling Speaker

The Community DX-IC8 is a high-performance, professional in-ceiling loudspeaker engineered to deliver exceptional audio clarity, wide coverage, and reliable performance in commercial, educational, and architectural environments. Designed with Community’s renowned acoustic expertise, the DX-IC8 features precision-engineered drivers and a custom-tuned crossover network that ensures consistent frequency response, clear midrange reproduction, and detailed high frequencies, providing intelligible speech and music playback even in challenging acoustic spaces. Its compact, low-profile design allows seamless integration into ceilings without sacrificing aesthetic appeal, making it ideal for offices, retail environments, conference rooms, and public address applications. The DX-IC8 supports high power handling and low distortion, ensuring dependable performance under continuous operation, while its advanced baffle and enclosure design minimize resonances and optimize sound projection. With wide dispersion characteristics, the speaker provides uniform coverage across listening areas, eliminating hotspots and dead zones to maintain clarity throughout the space. Installation is simplified through innovative mounting hardware, secure clamps, and a rotatable backcan that accommodates various ceiling types and tile systems, reducing setup time for integrators and contractors. Its rugged construction and reliable components ensure long-term durability in commercial environments, while the magnetic grille and optional paintable finish provide a clean, professional appearance that blends seamlessly into interior designs. Altogether, the Community DX-IC8 offers a versatile, high-quality audio solution that combines clarity, durability, and installation flexibility, delivering reliable, intelligible, and musically accurate sound for a wide range of professional audio applications where performance and discretion are equally important.

Specifications

Operating Mode

• Passive with DSP.

Operating Environment

• Indoor.

Operating Range (-10 dB)

• 60 Hz to 20 kHz.

Nominal Beamwidth (H × V)

• 100°, conical.

LF

• 1 × 8" (165 mm).

HF

• 1 × 1.25" (32 mm) exit compression driver.

Nominal Maximum SPL

• Peak: 123 dB; Continuous: 117 dB.

Autoformer

• 70 V: 120 W, 60 W, 30 W, 15 W; 100 V: 120 W, 60 W, 30 W.

Recommended Amplifiers

• 150 W – 300 W @ 8 Ω (35 V – 49 V).

Input Connection

• 4-position Euroblock connector.

Controls

• Front-face wattage / low impedance selector switch.

Mounting Provisions

• 4 SpringLock mounting clamps with 3-inch grip range.

Certifications

• ETL listed for UL1480, UL2043, CSA62368-1; suitable for air-handling spaces (NFPA 70 / 90).

Included Accessories

• C-Ring plate, tile bridge rails, grille, paint mask, cut-out template.

Cutout Diameter

• 12.20" (310 mm).

Dimensions (Dia × D)

• 13.43" (341 mm) × 8.51" (216 mm).
